WAR Series Standard Specifications
| Construction: | Continuously welded unibody design |
| Understructure: | 8″ I-Beam @ 13.0#/ft. long rails No Crossmembers |
| Floor: | 3/16″Hardox® 450 OR 1/4″ Hardox® 450 |
| Sides: | 3/16″ OR 1/4″ Hardox® 450 4″ x 4″ 1/4″ structural tubing top rails 10″ full depth rear corner post and rear skirt |
| Tailgate: | 3/16″ OR 1/4″ Hardox® 450 Single “Picture Frame” Tailgate is standard Flush mounted steel tailgate hardware with 1-1/4″ hinges and pins |
| Front Bulkhead: | 3/16″ OR 1/4″ Hardox® 450 |
| Dimensions: | Lengths –10′ – 20′ |
Features & Benefits of Warren WAR (Demolition) Series Bodies
- Hardox® 450 Abrasion Resistant Steel Construction
- Continuous welding throughout body for additional strength
- Available in 10′-20′ lengths
- Full depth rear corner post with full depth rear crossmember
Body and Hoist Model:
| WAR-10 | T10-5383, U50-723, or U60-823 |
| WAR-11 | U60-823 or T11-63101 |
| WAR-12 | U70-824 or VTLW-63101 |
| WAR-13 | U110-8824 or VTLW-63110 |
| WAR-14 | U110-8824 or VTLW-63110 |
| WAR-15 | VTLW-63124 |
| WAR-16 | VTLW-63124 or VTLW-74135 |
| WAR-17 | VTLW-74135 |
| WAR-18 | VTLW-74170 |
| WAR-19 | VTLW-74170 |
| WAR-20 | VTLW-74170 or VTLW-85190 |
High Lift Tailgates
One of our most common options on a WAR dump body is an air high lift tailgate. Because, this option yields 26″ of clearance between the top of the side walls and tailgate. As a result, large objects and debris can easily flow out of the dump body. Additionally, we offer the high lift tailgate option with hydraulic cylinders in lieu of air cylinders.
WAR Body Options:
- Electric Tarp Systems
- Various Panel Tailgates
- Various Length/Width Cab Shields
- Heavy Duty Push Aprons
- Custom Paint
- Custom Light/Strobe Packages
